2010-2016 KLX110 143cc Kit w/Stage 2 Cam

TBparts 143cc big bore stage 2 cam kit for 2010-2016 Kawasaki KLX110. TBparts proven 143cc big bore kit combined with a new stage 2 cam for one of the best power combinations possible! These parts work flawlessly together to deliver a professional level of power. The cylinder is ceramic coated and all aluminum. The 60mm 143cc piston is made for the stock cylinder head and 91+ octane pump fuel. When combined with this  stage 2 kit you get as much power as possible without noticing any low end power loss. The new cam has more lift and faster ramp speeds to open the valves quicker, the combination lets more air and fuel in to make more power! Not to mention the installed/included brand new NTN bearings for a high quality perfect fit.

Key Features

• Super high quality/lightweight, high compression 10.5:1 domed 60mm piston, with rings, pin, & clips pump 91+ octane gas friendly. (for the stock, Zongchen ZS, and our older V1 cylinder heads)
• Ceramic coated all aluminum cylinder (no steel sleeve)
• Head gasket kit – Now includes the cylinder head o-ring set and an exhaust gasket
• Brand new camshaft w/NTN bearings made to OEM spec for a perfect fit.
• More valve lift than OEM to let more fuel & air in for more power
• Faster ramp speed opens the valves up quicker to let more fuel & air in for more power
• Includes cam gear to complete installation.
• Race cam without decompression mechanism
• AMAZING value!

Non Decompression – This cam kit does not reuse the OEM decompression gear.

This kit does not require boring of the case – simply bolt on and go! There are no installation instructions, but if you can replace your piston, you can install this kit. If you don’t have any experience working on your engine, we highly recommend having a professional technician install this kit or, at a minimum, purchasing the shop manual for your bike available from your local Kawasaki dealer. The parts are installed in the same manner as the OEM parts.

KLX110 Jetting  – A good base tune is: Pilot jet #42 and main jet #95. Pilot jet kit –TBW1458 Main jet kit –TBW0294 & TBW1584
